3928 Lawnwood St
Fort Worth, Texas 76111-6539
Phone: 817.831.2626 Fax: 817.831.8258
www.solidiform.com
T4
PURCHASE ORDER:083554
T4 Number:
Starting Control #:
Service Date:
VENDOR
Central Texas Heat Treating & Testing, Inc.
5801 Denton Hwy
Ft.Worth , TX 76148-3758
ORDER DATE DATE REQUIRED
3/14/2023 3/21/2023
BUYER SHIPPING METHOD
SIMON COMPANY VAN
T4
CERTIFICATIONS REQUIRED

(356, A356, E357, F357) T4 Solution: 10Hrs – 0 min / + 60 min at 1000° F ± 10°
(A357, D357) T4 Solution: 10Hrs – 0 min / + 60 min at 1010° F ± 10°
(C355) T4 Solution: 6 Hrs ± 20 min. at 985° F ± 10°
All ink stamping applied by processor must not be on or immediately adjacent to any raised cast numbers unless specified by drawing.
LN QTY MATL SVC SPEC  REV OEM PART NUMBER/REV BP EO/ECN PL MPI WORK ORDER CTL # SOLN AGE PO: CUST/OEM
1 48 A356 T4 AMS-2771  F LOCKFW 16K0548-13/D D 801I6-009 H POIS: NA 10939/1 231336 28901 28919 JB-2000842 /
Process Code: 607 a) Material: AMS-4218 (A356). b) Heat Treat per AMS-2771. c) T4 Solution: 10Hrs – 0 min / + 60 min at 1000° F ± 10° d) Start of Water Quench temp: Range 150° F – 170° F.
2 20 A356 T4 AMS-2771  F LOCKFW 16Y645-7/E E NA F POIS: NA 10984/1 231337 28901 28924 6537728900 /
Process Code: 607 a) Material: AMS-4218 (A356). b) Heat Treat per AMS-2771. c) T4 Solution: 10Hrs – 0 min / + 60 min at 1000° F ± 10° d) Start of Water Quench temp: Range 150° F – 170° F.
3 2 A356 T4 AMS-2771  F WOODMPC 3FP4759001-9/E E NA NA NL: NA 11051/1 231328 28901 28924 6600497261 /
a) Material: AMS-A-21180 (A356). b) Heat Treat per AMS-2771. c) T4 Solution: 10Hrs – 0 min / + 60 min at 1000° F ± 10° d) Start of Water Quench temp: Range 150° F – 170° F.
4 60 A356 T4 AMS-2771  F LOCKFW 16C0080-7/M M NA L POIS: NA 10949/1 231338 28901 28922 755819 / 6500006988
Process Code: 607 a) Material: AMS-4218 b) Heat Treat per AMS-2771. c) T4 Solution: 10Hrs – 0 min / + 60 min at 1000° F ± 10° d) Start of Water Quench temp: Range 150° F – 170° F.
5 60 A356 T4 AMS-2771  F LOCKFW 16C0080-9/M M NA L POIS: NA 10980/1 231339 28901 28922
a) Material: AMS-4218 b) Heat Treat per AMS-2771. c) T4 Solution: 10Hrs – 0 min / + 60 min at 1000° F ± 10° d) Start of Water Quench temp: Range 150° F – 170° F.
6 47 356 T4 BPS-4139  R BELLFW 206-011-721-009C/Y Y 127244-1 AB ODS: NC 11049/1 231340 28901 28907 47317-R1 / 4501158905
*****(MAF) Flight Safety Part***** a) Material: AMS-4217 b) Heat Treat per BPS-4139.
7 40 356 T4 BPS-4139  R BELLCN 206-001-360-001C/K K 206AA5482 K MEPI: NA 11012/1 231341 28901 28907 46302-R3 / 4501309549
a) Material: AMS-4217 (356-T6). b) Heat Treat per BPS-4139. c) T4 Solution: 10Hrs – 0 min / + 60 min at 1000° F ± 10° d) Start of Water Quench temp: Range 150° F – 170° F.
Refer to BHTI secure web site (https://info.bhti.com/) for current Bell Specification Revisions.
Processing to be accomplished in performance of this purchase order is directly related to a Lockheed Martin Aeronautics Company purchase order and must be accomplished in accordance with process specification(s) on this purchase order and the revision in effect as of the date of this PO of Lockheed Martin Aeronautics Company Appendix QJ, QX, Q4R and EMAP. All requirements of such Appendix QJ paragraph E 1- 5 shall be accomplished. All requirements of Appendix QX paragraph 1.5 a. - d. shall be accomplished. Appendices are located at http://www.lockheedmartin.com/material-management/ .
WORK MUST BE IN ACCORDANCE WITH REQUIREMENTS POSTED ON OUR SUPPLIER WEB SITE: http://www.solidiform.com/supplier/
